Enclustra Mercury+ ST1 - Jumper Settings VCC_IO_B; Jumper Settings VCC_IO_C

Jumper Position Source Description
1-2 , 6-8 VCC_OUT_A VCC_OUT_A is suppling VCC_IO_A & B
7-8 VCC_3V3 VCC_3V3 is suppling VCC_IO_B
9-10 VCC_OUT_B VCC_OUT_B is suppling VCC_IO_B
9-11, 10-12 VCC_OUT_B VCC_OUT_B is suppling VCC_IO_B & C
11-13, 10-12 VCC_1V2 VCC_1V2 is suppling VCC_IO_B & C
Table 20: Jumper Settings VCC_IO_B
Jumper Position Source Description
1-2 , 6-8, 10-12 VCC_OUT_A VCC_OUT_A is suppling VCC_IO_A, B & C
11-13 VCC_1V2 VCC_1V2 is suppling VCC_IO_C
9-11 VCC_OUT_B VCC_OUT_B is suppling VCC_IO_C
12-14 VCC_FMC_VIOB VCC_FMC_VIOB is suppling to VCC_IO_C
Table 21: Jumper Settings VCC_IO_C
Warning!
Use only VCC_IO_A, B and C voltages compliant with the equipped Mercury module; any other voltages
may damage the equipped Mercury module, as well as other devices connected to Mercury+ ST1 base
board.
Figure 11 shows the pin numbering for connector J1602 and provides one configuration example.
