4.3 Fan Connector (J1601)
An external 12 V fan can be connected to J1601 connector.
Pin Number Signal Name Description
1 GND Ground
2 VCC_MAIN 12 V DC (nominal) input voltage
3 NC -
Table 10: J1601 - Fan Connector
Type Manufacturer
61900311121 Würth Elektronik
Table 11: J1601 - Fan Connector Type
Table 12 shows an example of a mating part for the fan connector. This connector is without female crimp
contacts or wires.
Type Manufacturer
61900311621 Würth Elektronik
Table 12: Mating Part for the Fan Connector
4.4 I/O Voltage Selection (J1602)
The I/O voltage selection jumpers are used to configure the VCC_IO_A, VCC_IO_B and VCC_IO_C voltages
that power the I/O banks of the SoC/FPGA device on the Mercury module. Refer to Section 5.6 for details.
4.5 Mercury Module Connector (J200/J201/J300)
A detailed pinout of the Mercury module connector can be found in the Mercury Master Pinout [9] and in
the Mercury+ ST1 Base Board User Schematics [4].
Warning!
Only Enclustra Mercury FPGA/SoC modules should be inserted into the Mercury+ ST1 base board.
Warning!
The VCC_IO pins are directly connected to the FPGA/SoC device. Apply only compliant voltages to
the VCC_IO pins; any other voltage may damage the mounted Mercury FPGA/SoC module, as well as
other devices on the Mercury+ ST1 base board.
D-0000-456-001 19 / 48 Version 02, 23.07.2020
