Commissioning with an operating menu (onsite display/FieldCare) Cerabar M, Deltabar M, Deltapilot M
126 Endress+Hauser
Unit after lin. (038)
Options
Select the unit (unit of the Y-value).
Options:
•%
• cm, dm, m, mm
•hl
•in
3
, ft
3
, m
3
•l
•in, ft
•kg, t
•lb
•gal
•Igal
Factory setting:
%
Line numb. (039)
Entry
Enter the number of the current point in the table.
The subsequent entries in "X-value (040) (manual entry)" and "Y-value (041)
(manual entry/in semi-auto. entry)" refer to this point.
Input range:
• 1 ... 32
X-value (040) (manual
entry)
X-value (123) (in linear/
activ table)
X-value (193) (in semi-
auto. entry)
Entry/Display
Enter the X-value (value before linearization) for the specific point in the table and
confirm.
• If "Lin. mode (037)" = "Manual", the level value must be entered.
• If "Lin. mode (037)" = "Semiautomatic", the level value is displayed and must be
confirmed by entering the associated Y-value.
Y-value (041) (manual
entry/in semi-auto.
entry)
Y-value (194) (in linear/
activ table)
Entry/Display
Enter the Y-value (value after linearization) for the specific point in the table.
The unit is determined by "Unit after lin. (038)".
The linearization table must be monotonic (increasing or decreasing).
Edit table (042)
Options
Select the function for entering the table.
Options:
• Next point: The "Line numb." parameter is increased by 1. The next point can be
entered.
• Current point: stay on the current point to correct a mistake for example.
• Previous point: The "Line numb." parameter is decreased by 1. The previous point
can be corrected/entered again.
• Insert point: insert an additional point (see example below).
• Delete point: delete the current point (see example below).
Example: Add a point - in this case between the 4th and 5th point for example
– Select point 5 via the "Line numb. (039)" parameter.
– Select the "Insert point" option via the "Edit table (042)" parameter.
– Point 5 is displayed for the "Line numb. (039)" parameter. Enter new values for
the "X-value (040) (manual entry)" and "Y-value (041) (manual entry/in semi-
auto. entry)" parameters.
Example: Delete a point - in this case the 5th point for example
– Select point 5 via the "Line numb. (039)" parameter.
– Select the "Delete point" option via the "Edit table (042)" parameter.
– The 5th point is deleted. All of the subsequent points are moved up one number
i.e. following deletion, the 6th point becomes Point 5.
Factory setting:
Current point
Tank description (173)
Entry
Enter the tank description (max. 32 alphanumeric characters)
Tank content (043)
Display
Displays the level value after linearization.
Parameter name Description
