Troubleshooting Cerabar M, Deltabar M, Deltapilot M
224 Endress+Hauser
Explanation of XD_ERROR and BLOCK_ERROR
• F = failure
• M (warning) = maintenance required
• C (warning) = function check
• S (warning) = out of specification (deviations from the permitted ambient or process
conditions determined by the device with the self-monitoring function, or errors in the
device itself indicate that the measuring uncertainty is greater than what would be
expected under normal operating conditions).
Error type Code XD_ERROR
Value
XD_ERROR Text BLOCK_
ERROR bits
BLOCK_ERROR Text PV Status
F (failure) 2, 62, 81, 83 20 Electronics failure 8 Sensor failure Bad Sensor failure
140 20 Electronics failure 8 Sensor failure Bad Sensor failure
261, 282 20 Electronics failure 9 Memory failure Bad Device failure
283 23 Data integrity
error
11 Lost NV data Bad Device failure
510, 511,
512
19 Configuration
error
13 Device needs maintenance
now
Bad Configuration error
841 17 General error 8 Sensor failure Bad Sensor failure
882 22 I/O failure 0 Other Bad Non-specific
(M) warning 2 17 General error 8 Sensor failure Uncertain non-specific
283, 402 23 Data integrity
error
11 Lost NV data Uncertain non-specific
434, 515 18 Calibration error 13 Device needs maintenance
now
Uncertain non-specific
438 23 Data integrity
error
10 Lost static data Uncertain non-specific
472 17 General error 6 Device needs maintenance
soon
Uncertain non-specific
882 22 I/O failure 0 Other Uncertain sub-normal
(C) warning 484, 485 17 General error 0 Other Uncertain non-specific
824 20 Electronics failure 8 Sensor failure Uncertain Non-specific
(S) warning 110 20 Electronics failure 8 Sensor failure Uncertain Sensor conversion not
accurate
140 20 Electronics failure 8 Sensor failure Uncertain Sensor conversion not
accurate
822 17 General error 8 Sensor failure Uncertain
Sensor conversion not accurate
841 17 General error 8 Sensor failure Uncertain
Sensor conversion not accurate
