Deltabar PMD78B PROFINET with Ethernet-APL Mounting
Endress+Hauser 25
Item T
a
1)
T
p
2)
–50 °C (–58 °F) 50 °C (122 °F)
–35 °C (–31 °F) –70 °C (–94 °F)
C 60 °C (140 °F) 200 °C (392 °F)
3)
85 °C (185 °F) 85 °C (185 °F)
–50 °C (–58 °F) 10 °C (50 °F)
–30 °C (–22 °F) –70 °C (–94 °F)
D 67 °C (153 °F) 200 °C (392 °F)
3)
85 °C (185 °F) 85 °C (185 °F)
–50 °C (–58 °F) 10 °C (50 °F)
–30 °C (–22 °F) –70 °C (–94 °F)
1) Maximum ambient temperature at transmitter
2) Maximum process temperature
3) Process temperature: max. +400 °C (+752 °F), depending on the fill fluid used
5.2.5 Seal for flange mounting
NOTICE
Seal pressing against the membrane!
Incorrect measurement results!
‣
Ensure that the seal is not touching the membrane.
1 2
A0017743
1 Membrane
2 Seal
5.2.6 Wall and pipe mounting
A0031326
