Level measurement (FF configuration program) Cerabar S/Deltabar S/Deltapilot S FOUNDATION Fieldbus
14 Endress+Hauser
5 Level measurement (FF configuration program)
In this chapter the parameter text as well as the parameter name are indicated. In FF configuration
programs only the parameter text is displayed (exeption: in the NI-FBUS configurator you can select
if the parameter text or the parameter name is displayed).
P01-xxxxxxxx-07-xx-xx-en-001
5.1 Overview of level measurement
Parametertext Parametername
Linearization/LINEARIZATION
Measuring task LEVEL
SELECTION/
LEVEL MODE
Measured variable
options
LEVEL_TYP/
LEVEL MODE
Description Measured value display
The measured variable is
in direct proportion to the
measured pressure.
LEVEL SELECTION:
Level easy pressure
– % (level)
– Level
–Volume
–Mass
Linear Calibration without
reference pressure – dry
calibration, see → ä 25,
→ Chap. 5.4.2
The measured value display and
the Primary Value Type/
PRIMARY_VALUE and Level
Before Lin./LEVEL_BEFORE_
LINEARISATION parameters
display the measured value.
The measured variable is
not in direct proportion to
the measured pressure as
is the case with tanks with
a conical outlet, for
example. A linearization
table has to be entered for
the calibration.
LEVEL SELECTION:
Level standard/
LEVEL MODE:
Pressure linearized
– Pressure and %
– Pressure and
volume
– Pressure and mass
Pressure linearized – Calibration with
reference pressure:
semiautomatic entry of
linearization table, see
→ ä 27,
→ Chap. 5.5.1.
– Calibration without
reference pressure:
manual entry of
linearization table, see
→ ä 29,
→ Chap. 5.5.2.
The measured value display and
the Primary Value Type/
PRIMARY_VALUE parameter
show the measured value.
– Two measured variables
are required or
– The container shape is
given by value pairs,
such as height and
volume.
The 1st measured variable
%-height or height must be
in direct proportion to the
measured pressure. The
2nd measured variable
volume, mass or % must
not be in direct proportion
to the measured pressure.
A linearization table has to
be entered for the 2nd
measured variable. The
2nd measured variable is
assigned to the 1st
measured variable by
means of this table.
LEVEL SELECTION:
Level standard/
LEVEL MODE:
Height linearized
–Height and volume
–Height and mass
–Height and %
– %-height and
volume
– %-height and mass
– %-height and %
Height linearized – Calibration without
reference pressure: dry
calibration and manual
entry of linearization
table, see → ä 31,
→ Chap. 5.6.1.
The measured value display and
the Primary Value Type/
PRIMARY_VALUE parameter
show the 2nd measured value
(volume, mass or %).
The Level Before Lin./LEVEL_
BEFORE_LINEARISATION
parameter displays the 1st
measured value (%-height or
height).
