Cerabar S/Deltabar S/Deltapilot S FOUNDATION Fieldbus Graphic representation of function groups
Endress+Hauser 11
3 Graphic representation of function groups
3.1 Representation via device display
!
Note!
The "Flow" measuring mode is only available for the Deltabar S differential pressure transmitter. The
groups marked with "*" are only displayed for Deltabar S.
1. Group selection 2. Selection level 3. Function group Description,
see page
LANGUAGE LANGUAGE (079) → 133
MEASURING MODE MEASURING MODE (389) → 134
Depending on the MEASURING MODE selected (pressure, level or flow), the QUICK SETUP is set to pressure, level or flow.
QUICK SETUP (pressure) → 136
QUICK SETUP (level) → 138
QUICK SETUP (flow *) → 133
OPERATING MENU → SETTINGS (557) → POSITION ADJUSTMENT → 142
→ BASIC SETUP (pressure) → 144
→ BASIC SETUP (level),
"Level easy pressure"
→ 146
→ BASIC SETUP (level),
"Level easy height"
→ 150
→ BASIC SETUP (level),
"Level standard"
→ 155
→ BASIC SETUP (flow) * → 178
→ EXTENDED SETUP (pressure) → 183
→ EXTENDED SETUP (level) → 183
→ EXTENDED SETUP (flow) * → 185
→ LINEARIZATION – local operation → 186
→ LINEARIZATION – FieldCare → 189
→ TOTALIZER SETUP * → 192
→ DISPLAY (555) → 194
→ TRANSMITTER INFO (560) → FF-DATA → 199
→ TRANSMITTER DATA → 196
→ PROCESS CONNECTION → 197
→ SENSOR DATA → 198
→ PROCESSINFO (561) → PROCESS VALUES (pressure) →
200
→ PROCESS VALUES (level) → 201
→ PROCESS VALUES (flow) * → 202
→ FUNCTION BLOCKS → 203
→ PEAK HOLD INDICATOR → 203
→ OPERATION → 205
→ DIAGNOSTICS → SIMULATION MODE → 206
→ MESSAGES → 207
→ USER LIMITS → 208
