Table 7: OPERATING MENU → SETTINGS → BASIC SETUP "Pressure"
Parameter name Description
Prerequisite:
• MEASURING MODE = Pressure
Note:
See also
– → ä 136, Table 3: QUICK SETUP "Pressure"
– → ä 183, Table 15: OPERATING MENU → SETTINGS → EXTENDED SETUP "Pressure"
– → ä 200 ff, Table 27: OPERATING MENU → PROCESSINFO → PROCESS VALUES "Pressure"
– → ä 104 ff, Section 8 "Pressure measurement (via local operation and FieldCare)".
MEASURING MODE
Selection
Select the measuring mode.
The operating menu is structured according to the selected measuring mode.
!
Note!
When the measuring mode is changed, no conversion takes place. The digital output
value of the Analog Input Block OUT no longer displays the same value as the local
operation or the MEASURED VALUE. The device has to be recalibrated if the measuring
mode is changed. → ä 104, Section 8 "Pressure measurement (via local operation and
FieldCare)".
Options:
• Pressure
• Level
•Deltabar S: Flow
Factory setting:
Pressure
PRESS. ENG. UNIT (060)
Selection
Select the pressure unit.
If a new pressure unit is selected, all pressure-specific parameters are converted and
displayed with the new unit.
Options:
• mbar, bar
• mmH2O, mH2O, inH2O, ftH2O
• Pa, hPa, kPa, MPa
•psi
• mmHg, inHg
•Torr
•g/cm
2
, kg/cm
2
•lb/ft
2
•atm
•gf/cm
2
, kgf/cm
2
•User unit, → see also the following parameter descriptions for CUSTOMER UNIT P
and CUST. UNIT FACT. P.
!
Note!
Following a change in the unit, the digital output value of the Analog Input value OUT
and the local operation or the MEASURED VALUE no longer display the same value.
→ See also parameter descriptions for XD SCALE, OUT SCALE and OUT value.
Factory setting:
Depends on the sensor nominal measuring range mbar or bar or as per order
specifications
CUSTOMER UNIT P (075)
Entry
Enter text (unit) for customer-specific pressure unit.
You can enter a maximum of eight alphanumeric characters here. → See also CUST.
UNIT. FACT. P
Prerequisite:
• PRESS. ENG. UNIT = User unit
!
Note!
Only the first five characters are shown on the local operation. For example, if the
customer-specific unit "crates" was selected, only "crate" would be displayed.
If the unit contains a slash, up to eight characters can be shown on the local operation.
The maximum number of characters in the counter is again limited to five. For example if
the customer-specific unit "crates/m2" was selected, "crate/m2" would be displayed.
FieldCare accepts units with eight characters at most. The slash counts as one character.
Factory setting:
_ _ _ _ _ _ _ _
To Next Page
