Installing Optional Mini-GBICs
3-24 Hardware Installation
Figure 3-17 Mini-GBIC with RJ45 Connector
1 SFP Slot 3 Release tab
2 Mini-GBIC
(MGBIC-02) 4 Link/Activity LED
27
28
A2H124-24P
25
26
27
28
25/Up 26/Down
Stack
