Mini-GBIC Input/Output Specifications
A-4 Specifications
Mini-GBIC Input/Output Specifications
TheMini‐GigabitEthernetCard(Mini‐GBIC)portinterfaceslotscansupport1‐Gbps
fiber‐opticconnectionsasdescribedinTable A‐3.Theop tionalMini‐GBICsarehot
swappable.
Gigabit Ethernet Specifications
ThefollowingspecificationsfortheMini‐GBICsshowninTable A‐4throughTable A‐12
meetorexceedtheIEEE802.3z‐1998standard.
MGBIC-LC01/MGBIC-MT01 Specifications (1000BASE-SX)
Table A-3 Mini-GBIC Input/Output Port Specifications
Item Specification
MGBIC-LC01 Provides one LC fiber-optic multimode port that is compliant with the
1000BASE-SX standard LC connector.
MGBIC-LC03 Provides one LC Long Haul (up to 2 KM) fiber-optic multimode port
that is compliant with the 1000BASE-SX standard LC duplex style
connector.
MGBIC-LC09 Provides one LC fiber-optic single-mode port that is compliant with the
1000BASE-LX standard LC connector.
MGBIC-MT01 Provides one MT-RJ fiber-optic multimode port that is compliant with
the 1000BASE-SX standard MT-RJ connector.
MGBIC-08 Provides one LC fiber-optic single-mode port that is compliant with the
1000BASE-ELX standard LC connector.
MGBIC-02 Provides one RJ45 copper connection that is compliant with the
1000BASE-T standard RJ45 connector.
Table A-4 MGBIC-LC01/MGBIC-MT01 Optical Specifications
Item 62.5 µm MMF 50 µm MMF
Transmit Power (minimum) -9.5 dBm -9.5 dBm
Receive Sensitivity -17 dBm -17 dBm
Link Power Budget 7.5 dBm 7.5 dBm
