Installing Optional Mini-GBICs

SecureStack A2 PoE Installation Guide 3-31

1. Removetheprotectivecovers(notshown)fromthefrontpanelLCfiber‐opticport

(port27inthisexample)andfromtheconnectorsoneachendofthecable.

2. InserttheLCcableconnectorintotheMini‐GBICLCconnectoruntilitclicksinto

place.

Figure 3-21 Cable Connection to LC Fiber-Optic Connectors

3. Plugtheotherendofthe

cableintotheappropriateportontheotherdevice.Some

cablesmaybeterminatedattheotherendwithtwoseparateconnectors,oneforeach

fiber‐opticstrand.Inthiscase,ensurethatthetransmitfiber‐opticstrandisconnected

tothereceiveportandthereceivefiber‐opticstrandto

thetransmitport.

Note: Leave the protective covers in place when the connectors are not in use to prevent

contamination.

Note: To remove the LC cable connector, press on its release tab and pull it out of

Mini-GBIC LC connector.

1 Mini-GBIC MT-RJ port connector 3 Release tab

2 LC cable connector 4 Link/Activity LED

A2H124-24P

25/Up 26/Down

Stack
