Switch Specifications
A-2 Specifications
AC Input Specifications
Input Voltage 100 to 240 VAC
Input Currrent 5.1 A Max
Frequency 50 to 60 Hz
Processors/Memory
Processor MPC8241, 266 MHz processor
Dynamic Random Access
Memory (DRAM)
128 MB
FLASH Memory 16 MB
Physical
Dimensions 4.4 H x 44.1 W x 21.0 D cm (1.7 H x 17.4 W x 8.27 D in.)
Approximate Weight Gross:
Net:
6.8 kg (14.99 lb) (shipping carton
containing one module)
5.78 kg (12.74 lb) (one module
without packaging)
Predicted hours for Mean Time
Between Failures (MTBF)
201,377 hours
Heat Dissipation (maximum) @ 29.01 W, 1522 Btu/hr
Environmental
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Operating Relative Humidity 5% to 95% (non-condensing)
Table A-1 A2H124-24P Switch Specifications (continued)
Item Specification
