Stove Operation - Circuit Board

dHC 4110 sTarT-uP sequenCe (15 minuTes) - manual mode, FaCTory seTTing:

NOTE: No Thermostat or Wall Switch -

All control of circuit board function is adjusted at the circuit board.

Note: Fuel Type can only be changed when the unit is cold. The thermostat mode can be changed during

normal operation.

1. Push the ON/OFF button to start. The stove may take up to 30 seconds to establish rebox vacuum.

The Fuel Type Light will flash (the Auger Feed Rate is pre-programmed during start-up).

3. The Heat Level Indicator will show the Heat Level that the stove will run at after start-up.

4. The ignitor comes on.

The agitator will not operate for the first ten (10) minute after the ON button has been pressed. After the

ten (10) minutes it will pulse at the same interval as the feed auger.

When the start-up sequence is complete the unit will ramp up to its heat level setting, this may take up to

fifteen (15) minutes.

7. Once a fire has been established, the convection blower will turn on after ten (10) minutes.

dHC 4110 normal oPeraTion - manual mode, FaCTory seTTing:

Press the Heat Level buttons to change the desired Heat Level Output setting.

The speed of the convection blower is controlled by the setting of the heat level.

The Feed Trim button pressed in conjunction with the Heat Level adjustment buttons to adjust the Feed Trim.

It can be increased by two (2) feed settings or it can be decreased by two (2) feed settings.

The M-55-FS has an automatic cleaning cycle; every thirty (30) minutes the agitator will turn continuously for

one (1) minute to help clean out the burn pot liner.

dHC 4110 sHuT down - manual mode, FaCTory seTTing:

1. Push ON/OFF button to turn stove off.

2. All the lights will turn off

3. The auger will stop feeding

The combustion blower goes to full speed until the exhaust temperature sensor opens, stopping all motors.

NOTE: On shut down the burn pot agitator will run continuosly for five (5) minutes on premium mode,

one (1) minute on regular mode, and five (5) minutes on multi-fuel mode.

dHC 4110 sTarT-uP sequenCe (15 minuTes) - HigH/low mode, wiTH THermosTaT or wall swiTCH:

Thermostat contacts open (it is satisfied) or closed (it is calling for heat) at time of start-up.
