Troubleshooting
Check all the electrical connections on
the exhaust temperature sensor located
on the exhaust channel.
Are the connections secure?
YES
Secure the connections.
NO
By-pass the ignitor temperature sensor, refer to
the hoW to’S For trouBleShooting - hoW to By-paSS
the 120°F ignitor temperature SenSor/SWitCh. Plug
the stove back in.
Does the ignitor work?
Replace the sensor.
140°F (60°C) - EF3 Timer Control
120°F (49°C) - All other models
YES
Replace the ignitor.
NO
Plug the ignitor in directly.
Does the ignitor work?
NO
ConTrol seTTings (HeaT level) Have no eFFeCT on THe Fire - CirCuiT Board only:
Is the system light is flashing?
YES
The control board has complete control of the unit.
When the unit’s system light becomes solid, then
control of the unit is given back to the operator.
Turn up the thermostat.
Circuit Board Only: When the unit is in the HIGH/
LOW mode does the unit not shut off; instead it
goes to an idle setting (LOW)?
Thermostat Equipped Circuit Board Only: Is
the thermostat turned down below the room
temperature (thermostat mode in the ON / OFF
position)?
NO
Turn down the temperature that the
thermostat is calling for.
Check the connections to the exhaust temperature
sensor, circuit board, start-up switch and the start-
up timer against the wiring diagram.
Are the connections correct and secure?
NO
Correct and secure the connections.
Press the ON/OFF button to turn the
unit off.
YES
THe sTove will noT sHuT oFF:
The unit may be in the 30 minute
low mode before shutdown
YES
To Next Page
