Troubleshooting
THe auger moTor will noT FunCTion normally:
Check the condition of the vacuum hose
(located on the left side of the stove).
Check to ensure hose barb is clear.
Is the vacuum hose cracked or torn?
Replace vacuum hose.
Is the vacuum hose installed on the top air
inlet tube on the vacuum sensor?
Install vacuum hose correctly on the barb
marked ‘L”. Are the wires in correct
position on vacuum switch?
NOTE: The Pre September 2008 vacuum
switch has 3 male connectors - never use
the center connection.
YES
NO
Check all connections against the unit’s wiring diagram.
Are all the connections correct?
Apply 115V AC directly to the auger motor with a test cord, refer to the hoW to’S
For trouBleShooting - hoW to apply direCt poWer to the auger motor.
Does the motor’s armature try to spin even though the auger gear box not turn?
Correct the
errors.
YES
NO
Replace the
auger motor.
NO
The auger is jammed. Try to break apart jam by poking at the jam through the
drop tube. If this fails then empty the hopper and remove the auger cover.
**Remember to re-seal the auger cover after installation**
YES
Has the reset button on the 200°F (93°C) temperature sensor been tripped?
By pass the 200°F (93°C) temperature sensor, refer to the hoW
to’S For trouBleShooting - hoW to By-paSS the 200°F manual reSet.
Does the auger works?
If this sensor has been
tripped find the reasons for
the over heating before
pushing red button in.
Check auger for
movement.
YESNO
Replace the 200°F (93°C) temperature sensor.
YES
NO
46
To Next Page
