Enviro EF2 Service Manual

The How To’s For Troubleshooting
How To By-Pass THe Fan ConTroller:
Female-Female
Connector
Fan Controller
Figure 24: By-Passing The Fan Controller.
This is for Timer Control models.
The fan controller is found on the inside of the
right cabinet side.
Use a female-female connector to by-pass the
fan controller as shown in Figure 24.
How To By-Pass THe 200°F manual reseT:
Female-Female
Connector
200
o
F Manual Reset
Figure 25: By-Passing The 200°F Manual Reset.
The 200°F manual reset is found behind
the right cabinet side.
Use a female-female connector to by-pass
the 200°F manual reset as shown in Figure
25.
Used in
trouBleShooting sections “the auger
motor Will not FunCtion normally“ & “the
auger light FlaSheS But the auger doeS not
turn at all“.
34
