Wiring Diagram
m55-Fs - dHC 4110:
Ignitor
Red
White
Red
White
Air Pump
Exhaust
Temperature
Sensor
Green
Ground
Brown
Brown
High Limit
Temperature
Switch
Orange
Orange
Purple
White
Convection
Blower
Agitator
Motor
Grey
Grey
Orange
Orange
White
Grey
Grey
White
Blue/Yellow
Auger
Motor
White
Yellow
Vacuum
Switch
Connect
Thermostat
Here
Brown
Brown
Blue
Purple
Yellow
Red
Thermostat
Combustion
Blower
Black
Black
White
Green
Ground
5 Amp
120V
Ground
Plug
Black
Black
Blue
White
Red
Black
Bl
ue
Blue
2µF Capacitor
69
