Enviro EF2 Service Manual

Refer to trouBleShooting - the dial-a-Fire haS no eFFeCt on the Fire .
Use a multimeter to check the voltage
across the load pins of the timing module.
Does the voltage read around 1V to 2V
then cycling to line voltage during an
auger pulse?
Replace the timing control module.
NO
By-pass the auger dial-a-fire control, refer to
the
h
oW to’S For trouBleShooting - hoW to By-paSS the
dial-a-Fire.
Does the auger now cycles very quickly?
NO
Test the dial-a-fire potentiometer, refer to
the
hoW to’S For trouBleShooting - hoW to meaSure
reSiStanCe aCroSS the dial-a-Fire.
Troubleshooting
THe auger Timer will noT FunCTion normally - Timer ConTrol only:
Is the dial-a-fire turned to
the ‘ON’ position’?
Turn knob clockwise to the ‘ON’ position. You should hear a
‘click’; if you do not the knob may need to be tightened.
NO
YES
YES
THe igniTor will noT work:
Everything else in the stove operates but the ignitor will not light the pellets.
Remove the burn pot and the burn pot liner and look
into the ignitor tube. Check the colour of the ignitor.
Is the ignitor bright orange in color?
Replace the ignitor.
NO
Check the burn pot liner placement. The burn pot
liner should be up tight and square to the ignitor tube.
Is the burn pot correctly positioned?
Correct positioning by pushing
the burn pot back against the
ignitor tube. Replace the liner if
it is warped.
NO
Is the exhaust blower is operating?
Refer to trouBleShooting - the ComBuStion
(exhauSt) motor Will not FunCtion normally.
NO
YES
YES
Circuit Board Only: Check the fuses on the circuit board (see “trouBleShooting - CirCuit Board FuSeS”).
Increase the airow by opening the damper.
YES
48
