Section 16: Specifications
210
Zing 24 x 12 Specifications
Maximum Engraving Area 24" x 12" (610 x 305 mm)
Maximum Material Thickness 7.5" (190.5 mm)
Laser Control Display Panel Displays stored file names, speed, power, runtime and more.
Intelligent Memory Buffer Store unlimited files up to 64 MB. Rolling buffer allows files of any size (64
MB and larger) to be engraved.
Operating Modes Optimized raster engraving, vector cutting, or combined raster/vector mode.
Laser Source State-of-the-art, digitally controlled, air-cooled CO2 laser tubes are fully
modular, permanently aligned, and field replaceable/upgradeable.
Belts Advanced B-style Kevlar precision drive belts.
Resolution User controlled choice of 100, 200, 250, 400, 500, or 1000 dpi.
Speed/Power Control Computer or machine controlled Speed and Power in 1% increments to 100%.
Color mapping links Speed and Power setting to any RGB color.
Print Interface 10 Base T Ethernet or USB connections. Compatible with 32 bit versions of
Windows XP, 2000 or Vista.
Standard Features Red Dot Pointer, Air Curtain (pump optional), 2" focus lens, relocatable home,
flash upgrade electronics.
Size/Weight 38" wide x 27.25" deep x 15" high (965 x 692 x 381mm)
140 lbs (64 kg)
Electrical Requirements Auto-switching power supply accommodates 100 to 240 VAC, 50 or 60 Hz,
single phase, 15 amp AC.
Ventilation External exhaust to the outside required. Output diameter at machine is 4" (100
mm).
Safety CDRH Class IIIR
Max Ambient Room Air 90 degrees F (32 C) Max Temperature
