9
1.3 Specification
Model eLite
Rated Input Power 500 W
Peak Input Power 750 W
Rated input voltage 25.2 Vdc
Input voltage range 19.25 Vdc - 29.4 Vdc
Weight 6.7 kg (without clamp bracket)
Adjustable Shaft Length Range (from top of
propeller to transom)
282.5 - 401 mm
Dimensions (Length * Width * Height,
without bracket clamp)
297 mm * 75 mm * 890 mm
(without bracket clamp)
Cooling Method Natural water cooling
Rated Power Rotational Speed Range 1450 - 1800 rpm
Operating Temperature -5 - 55
℃
Storage Temperature -20 - 45
℃
Operation and Interaction
Tiller with rotary throttle
Kill Switch
Display
Power Button
Propeller Two-blade propeller, diameter: 194mm
Tilt Angle 75°
Steering Angle ±70°
Battery Capacity 378 Wh
Battery Type Built-in non-removable battery
Waterproof Rating IP67
