ePropulsion eLite User Manual

15
2.2 Throttle Rotation
The direction of the motor – forwards or reverse – and the power input are controlled by rotation
of the throttle handle (at end of tiller). The F position is for forward, the N position is for neutral,
and the R position is for reverse.
Neutral is selected when the raised indicators on the tiller shaft and throttle handle are aligned.
The motor remains in Neutral a few degrees either side of that position when switching between
F and R.
Figure 2.3
2.3 Tiller Extension
The tiller can be extended by up to 13cm, for more convenient positioning in the boat. To do
this, press the button at the end of the tiller and pull it outwards. The tiller will automatically lock
back in place when it is fully retracted.
Figure 2.4
1 2 3
4
A
B
3 2 1
B
A
C
D
C
g
单位:mm
Guangdong ePropulsion Technology Limited
广东逸动科技有限公司
4
Tiller Extension Relsase
1 2 3
4
A
B
3 2 1
B
A
C
D
C
g
单位:mm
Guangdong ePropulsion Technology Limited
广东逸动科技有限公司
4
