ePropulsion eLite User Manual

46
Step 3: Retract the tiller fully and confirm it is locked.
Figure 10.3
Step 4: Use the tiller as a handle to carry the outboard motor.
Figure 10.4
1. When carrying the outboard motor do not subject it to excessive movement.
2. If putting the motor down, make sure the outboard is placed horizontally (with the
"eLite" logo facing up) on a solid surface. Do not place or balance it vertically or at an
angle, as this risks it falling over and becoming damaged or causing damage.
10.2 Outboard Bag
The ePropulsion eLite electric outboard motor comes with a outboard bag for carrying and
storing the outboard motor.
Figure 10.5
1 2 3
4
A
B
3 2 1
B
A
C
D
C
g
单位:mm
Guangdong ePropulsion Technology Limited
广东逸动科技有限公司
4
1 2 3
4
A
B
3 2 1
B
A
C
D
C
g
单位:mm
Guangdong ePropulsion Technology Limited
广东逸动科技有限公司
4
