19
Step 4: Push the trim pin inward and tighten it, then rotate it 180°.
Figure 3.7
3.3 Shallow Water Mode
The ePropulsion eLite outboard motor has a shallow water mode. This allows the outboard to be
partially tilted for continued operation in shallow water, such as when approaching a beach or
slipway.
In shallow water mode reverse gear must not be used, as the propeller may kick up out
of the water and cause injury.
Step 1: Lift the lever upward.
Figure 3.8
1
2
3
4
A
B
3
2
1
B
A
C
D
C
g
单位:mm
Guangdong ePropulsion Technology Limited
广东逸动科技有限公司
4
1
2
3
4
A
B
3
2
1
B
A
C
D
C
g
单位:mm
Guangdong ePropulsion Technology Limited
广东逸动科技有限公司
4
