Main Window
No. Name Description
1 Connect button Click this button to connect the machine with the computer.
2 Disconnect button Click this button to cut the connection between the machine and the computer.
3 Upload button Click this button to send the settings file to the machine.
4 Download button Click this button to send the machine’s settings to the computer.
5 Dial Registration Click [+] beside the machine icon to display the machine speed dialing, group
dialing and favorite settings.
6 Machine icon Click [+] beside the machine icon to display the machine information.
For details, refer to “Displaying Machine Information” on page 34.
Connecting to the Machine
1. Click .
When Local Setup Program is connected to the machine, “Connect Status: Online” appears.
Note:
While operations are being performed in Local Setup Program, the machine cannot be operated from
its control panel.
AcuLaser CX16NF Reference Guide
Using Local Setup Program 24
