Note:
❏ To manually specify settings for the IP address, subnet mask and gateway, set IP ADDR. SETTING
to SPECIFY.
❏ When entering the IP address, do not enter a class D (between 224.0.0.0 and 239.255.255.255) or
class E (between 240.0.0.0 and 255.255.255.255) IP address.
In addition, “255” cannot be entered as the last three digits of the IP address.
TCP/IP
Purpose
Enables or disables TCP/IP.
Options
DISABLE/ENABLE
Default
ENABLE
IP ADDR. SETTING
Purpose
Sets the IP address of this machine on the network.
Set s the subn et mas k of t he ne twor k. The subn et mas k all ows yo u to l imit acce ss to y our ma chin e
(for example, according to departmental divisions).
Sets the address of the router/gateway when a router/gateway is used on your network and you
allow users outside your network environment to print on your machine.
Options
AUTO/SPECIFY
Default
AUTO
(If IP ADDR. SETTING is set to SPECIFY)
IP ADDRESS: 0.0.0.0
SUBNET MASK: 255.255.255.0
GATEWAY: 0.0.0.0
Range
(If IP ADDR. SETTING is set to SPECIFY)
0 to 255 for each xxx triplet
Use the keypad to input each number; use the l and r keys to move between triplets.
Notes
A single digit number, such as “1”, cannot be input as “001”. Align the number on the left and
input “1” as “1 _ _”. Use the l and r keys to move between triplets.
The Back key can also be used for deleting. To cancel IP Address menu, hold down the Back key
for more than one second, and then press the Back key again after all settings have been cleared.
AcuLaser CX16NF Reference Guide
Understanding the Network Setting Menu 38
