Epson LX-300+II RTP

EPSON LX-300+II/300+II RTP/1170II Revision D
Appendix EEPROM Address Map 115
2EH,2FH Character table selection
0: PC 437 21: Code MJK
1: PC 850 22: Bulgaria
2: PC 860 23: Estonia
3: PC 863 24: PC 774
4: PC 865 25: ISO 8859-2
5: PC 861 26: PC 866 LAT
6: BRASCII 27: PC 866 UKR
7: Abicomp 28: Hebrew7
8: IS0 Latin 1 29: Hebrew8
9: Roman 8 30: PC862
10: PC 437Greek 31: PCAPTEC
11: PC 852 32: PC 708
12: PC 853 33: PC 720
13: PC 855 34: PCAR864
14: PC 857 35: PC 858
15: (reserved) 36: ISO8859-15
16: PC 866 37: PC771
17: PC 869 38: PC437 Slovenia
18: ISO Latin 1T 39: PC MC
19: ISO 8859-7 40: PC 1250
20: MAZOWIA 41: PC 1251
0000H
(PC 437)
0000H
(PC 437)
128: Italic U.S.A. 132: Italic DenmarkI
129: Italic France 133: Italic Sweden
130: Italic Germany 134: Italic Italy
131: Italic U.K. 135: Italic Spain I
30H,31H (reserved) 0000H 0000H
32H Line Spacing
1 to 255 by 0.0588 mm(1/432 inch),
00H:4.2 mm(1/6 inch: same as default)
00H
(4.2 mm)
00H
(4.2 mm)
33H
Auto line feed
Auto tear off
Skip over perforation
High speed draft
-----
-----
Tear off without FF
-----
b0: Auto line feed 0: Off 1: On
b1: Auto tear off 0: Off 1: On
b2: Skip over perforation 0: Off 1: On
b3: High speed draft 0: On 1: Off
b4: (reserved)
b5: (reserved)
b6: Tear off without FF 0:Off 1: On
b7: (reserved)
00H 00H
34H
Software
0 slash
Buzzer
-----
Auto CR
-----
-----
-----
b0: Software 0: ESC/P 1: IBM 2380 Plus
b1: 0 slash 0: Off 1: On
b2: Buzzer 0: On 1: Off
b3: (reserved)
b4: Auto CR (IBM) 0: Off 1: On
b5: (reserved)
b6: (reserved)
b7: (reserved)
00H 00H
Table A-13. EEPROM Address Map (continued)
Address Explanation Setting
QPIT
Settings
Factory
Settings
35H I/F mode selection
0: Auto I/F selection 2: Serial I/F
1: Parallel I/F 3: USB I/F
00H
(Auto)
00H
(Auto)
36H
Auto I/F wait time
setting
10: 10 sec.
30: 30 sec.
00: 10 sec.(same as default)
00H
(10 sec.)
00H
(10 sec.)
37H
Serial baud rate b0-b2:Serial baud rate
0: 19200 bps 3: 2400 bps 6: 300 bps
1: 9600 bps 4: 1200 bps 7: (reserved)
2: 4800 bps 5: 600 bps
00H
(19200)
00H
(19200)
-----
b3:(reserved)
Serial parity b4-b5:Serial parity
0: None 2: Odd
1: Even 3: Ignore
(None) (None)
Serial data length
b6:Serial data length
0: 8bit 1: 7bit
(8bit) (8bit)
ETX/ACK protocol b7:ETX/ACK protocol
0: Off 1: On
38H
IEEE1284.4 for Parallel
I/F
b0-b1:
0: Auto 1: On (for test) 2: Off
00H
(Auto)
00H
(Auto)
IEEE1284.4 for USB I/F b2-b3:
0: same as “IEEE1284.4 for Parallel I/F”
1: Auto (for test) 2: On (for test) 3: Off (for test)
Input Buffer
b4:
0: On(64Kbyte) 1: Off(1 byte)
(On) (On)
----- b5:(reserved)
Parallel I/F bidirectional
mode
b6:Parallel I/F bidirectional mode
0: On 1: Off
Pause Offline b7:Pause Offline
0: Off 1: On
39H *ACK timing data 00H 01H
3AH
*ACK timing data
(complement of 39H)
00H FEH
3BH Panel mask pattern 1
b0: LOAD/EJECT function
b1: LF/FF function
b2: TEAR OFF function
b3: Micro Adjust function
b4: (reserved)
b5: (reserved)
b6: (reserved)
b7: (reserved)
00H 00H
Table A-13. EEPROM Address Map (continued)
Address Explanation Setting
QPIT
Settings
Factory
Settings
