EPSON LX-300+II/300+II RTP/1170II Revision D
PRODUCT DESCRIPTION Operation 27
1.4.2.3 Default Setting
There are some parameters that can be changed by users and will be referred at the time of
initialization of the printer.
 Setting mode
1. Enters the Default setting mode.
The method of selecting language for “Usage of this mode” is printed.
2. Select language for “Usage of this mode” by LF/FF button.
Font LEDs show the language for “Usage of this mode” that is currently selected.
This section will be advanced one by one as the button is pressed and the On/Off/
Blink/2-Blink of those three LEDs will also be changed according to the selection.
3. Press Tear Off button.
The current setting and the “Usage of this mode” by selected language will be printed
on the paper set in the paper path at that time.
4. Select Menu by Tear Off button.
Font LEDs show the menu which is selected at that time. The selection will be
advanced one by one as the button is pressed and the combination of those three LEDs
status of On/Off/Blink/2-Blinks will be changed according to the selection.
5. Select setting value by LF/FF button.
Font LEDs and Pause LED show that menu’s value by status of On/Off/Blink/2-
Blinks. That value can be changed by pressing LF/FF button and the LEDs status of
On/Off/Blink/2-Blinks will be changed as the button is pressed.
6. When LF/FF button is pressed, the printer stores the last setting value in memory.
7. Repeat (4) to (6).
The other items can be changed in the same manner.
The menu selection will return to the first menu after the last menu selection is over.
8. Turn the printer off.
The setting is stored into non-volatile memory.
*1 This setting is effective when IBM 2380 (LX-300+II) or IBM2381 (LX-1170II) Plus
emulation is selected.
*2 Settings with bold weight mean the standard factory settings.
Table 1-27. Setting Menu
Item Setting / Value *
2
Page length for tractor
3 inch, 3.5 inch, 4 inch, 5.5 inch, 6 inch, 7 inch, 8inch, 8.5 inch,
11 inch, 70/6 inch, 12 inch, 14 inch, 17 inch
Skip over perforation OFF, ON
Auto tear off OFF, ON
Auto line feed OFF, ON
Print direction Bi-d., Uni-d., Auto
Software
LX-300+II: ESC/P2, IBM 2380 Plus
LX-1170II: ESC/P2, IBM 2381 Plus
0 slash OFF, ON
High speed draft OFF, ON
I/F mode Auto, Parallel, Serial, USB
Auto I/F wait time 10 seconds, 30 seconds
Baud rate
19200BPS, 9600BPS, 4800BPS, 2400BPS, 1200BPS,
600BPS, 300BPS
Parity None, Odd, Even, Ignore
Data length 8 bit, 7 bit
Parallel I/F bidirectional mode OFF, ON
Packet mode Auto, OFF
Character
table
Standard
version
Italic, PC437 , PC850, PC860, PC863, PC865, PC861, BRASCII,
Abicomp, Roman8, ISO Latin 1, PC858, ISO 8859-15
NLSP version
Italic, PC437, PC850, PC437, Greek, PC853, PC855, PC852,
PC857, PC866, PC869, MAZOWIA, Code MJK, ISO 8859-7,
ISO Latin 1T, Bulgaria, PC774, Estonia, ISO 8859-2, PC 866
LAT., PC 866UKR, PC APTEC, PC708, PC720, PCAR 864,
PC860, PC865, PC861, PC863, BRASCII, Abicomp, Roman8,
ISO Latin 1, PC858, ISO 8859-15, PC771, PC437 Slovenia,
PC MC, PC1250, PC1251
International character set
for Italic table
Italic U.S.A., Italic France, Italic Germany, Italic, U.K., Italic
Denmark 1, Italic Sweden, Italic Italy, Italic Spain 1
Manual feed wait time 1 second, 1.5 seconds, 2 seconds, 3 seconds
Buzzer OFF, ON
Auto CR
(IBM 2380/2381 Plus)
*1
OFF, ON
IBM character table
*1
Table2, Table1
