EPSON LX-300+II/300+II RTP/1170II Revision D
PRODUCT DESCRIPTION Physical Specifications 40
1.8.2 Physical Specifications for LX-1170II
 Physical Specifications (Without pull tractor)
 Dimensions: 546 x 275 x 159 mm (WxDxH)
Except knob, paper guide & paper supports
 Mass: Approx. 6.6 kg
 Appearance: See the figure below.
Figure 1-12. Appearance Without Pull Tractor (LX-1170II)

Physical Specifications (CSF)
 Dimensions: 546 x 440 x 377 mm (WxDxH)
Except knob, paper guide & paper supports
 Mass: Approx. 7.2 kg
 Appearance: See the figure below.
Figure 1-13. Appearance With CSF (LX-1170II)
546
570.2
275
328
163.5
197.7
546
570.2
275
439.4
163.5
376.6
