Chapter 4 Handling
163
4
*1 : The values for the Rotation Settings in the table are those when [Orientation] in [Page
Layout] tab is se to “Portrait.” When it is set to “Landscape,” the description is changed as
below.
"Normal, Rotate 180 Degrees" ➔ “Rotate 90 Degrees, Rotate 270 Degrees"
"Rotate 90 Degrees, Rotate 270 Degrees" ➔ "Normal, Rota
te 180 Degrees"
*
2 : By the combination of the specific paper type and the Symbol, the following conditions are
available.
Wrist Band & Code128 : Element = 5 dots (D-grade)
Wrist Band & Codabar : Element = 5 dots,
Element ratio = 2.5 (C-grade)
•Bar Height:Sets the element height with dots. Specified dots indicate the actual
print size.
•Adjust Bar Width: Narrows the element width when printing. Make sure to select it
only when the barcode is not clear enough to be read.
•HRI Character Position: Select the position of the HRI characters. Select [Do Not Print] when
not printing.
•HRI Font: Select the HRI character font size.
• Element Rati
o: Sets the thick element width by the ratio to the thin element width.
•Character Spacing:Sets the character spacing (interval) by the ratio to the thin element
width.
2
Click [Add].
The selected barcode font is saved and the font name is added to the font list.
When “Module” is set to an odd number and the resolution is changed by changing [Cate-
gory] or [Print Quality], the printed barcode size may be changed. The barcode size can be
checked by [Size Display] button.
The printing position is limited for some types.
• The barcode font can be registered up to 30.
• The barcode font setting can be overwritten by clicking [Save] after selecting the font
name from the font list and changing the setting.
• The barcode font setting can be deleted by clicking [Delete] after selecting the font name
from the font list.
• Test print is executed according to the setting by clicking [Print] after inputting the text in
the box.
To Next Page
