Chapter 1 Product Overview
57
1
Power Supply Unit (PS-180)
Material
No specific brominated flame retardants, such as PBBE and PBB, are used in this product.
AC cable selection
Select an AC cable that satisfies the following conditions.
•Safety standard product
•Plug with PE terminal
Ground connections
Be sure to ground for safety
Electric
characteristics
Input conditions Input voltage (rated): 90 to 264VAC
(100VAC -10% to 230VAC +15%)
Frequency (rated): 50/60 Hz ± 3 Hz
Power consumption (rated): 100VA
Output
conditions
Output voltage (rated): 24VDC ± 5%
Output current (rated): 2.0A
Output electric power (rated): 48VA
Output peak current: 4.5A
Case specifications Dimensions
(H × W × D)
68 × 136 × 32 mm {2.68 × 5.35 × 1.26"}
(excluding protrusions)
Weight Approximately 0.4 kg {14.11 oz} (excluding the AC cable)
Color Black (matte)
[Unit: mm]
68
136
32
To Next Page
