Chapter 1 Product Overview
33
1
Paper type Plain Media, Fine Media, PET Film
Form Fanfold paper
Paper width 50 to 108 mm
Black mark width 13 mm or more
Black mark length 9 mm or more
Black mark centering position 8.5 ± 1 mm
Black mark interval 15 mm or more
Paper thickness 0.119 to 0.151 mm
Pitch of perforated line: 203.2 to 304.8 mm
Form of perforated line Plain media : 1 mm uncut, 5 mm cut
Fine media : 1 mm uncut, 5 mm cut
PET film : 0.6 mm uncut, 8.4 mm cut
Number of folds 500 or less
• Do not use the paper with a hole or cutout.
• When using fanfold paper, the black marks must be at least 0.5 mm from the perforated
lines.
• Make sure to keep the same position of the black marks to the perforated lines (position
that can be detected by black mark sensor) when inserting the paper from either side in
order to use the paper inserting from reverse direction.
