Chapter 1 Product Overview
37
1
Paper type Synthetic Media Label
Form Roll paper
Backing paper width 30 to 112 mm
Label width 25.4 to 108 mm
Label length 50.8 to 1117.6 mm
When it is less than 15 {0.59”} to 50.8 {2”} mm, use the label of
“When removing right and left fringes only” in the illustration.
Gap between labels 3 to 6 mm
Edge cutoff on left/right side 2 ± 0.5 mm
Label edge R 2 mm or less
Paper thickness 0.195 mm
Roll paper core Outside diameter: 44.1 mm
External diameter Maximum 101.6 mm
Winding direction Printing face must be facing outside.
Do not use the paper with a hole or cutout.
