Epson TM-C3400 - Page 46

46
Die-cut Label / Roll paper
Top margin (inside the label): 2.0 mm (typical value)
Left and right margin (inside the label): 2.0 mm (typical value)
Bottom margin (inside the label): 2.0 mm (typical value)
Paper width
2.0 mm
11.0 mm or more
18.0 mm or more
(When auto-cutting)
2.0 mm
2.0 mm
Auto-cut position
Auto-cut position
Paper feeding direction
Print area
2.0 mm
2.0 mm
2.0 mm
Label area
1.5 mm1.5 mm
3.0 to 6.0 mm
Center of paper width
Backing paper
Print area width
