Epson TM-P20 Technical Reference Guide

21
Chapter 1 Product Overview
1
Offline
The printer automatically goes offline and stops printing under the following conditions. Once all of the
following conditions are cleared, the printer becomes online and ready to print.
 During power on until the printer is ready
 While roll paper is being fed using the Feed button
 When the roll paper cover is open
 When paper is out
 When an error has occurred
 While waiting for the switch for executing the macro to be on
 While the printer is shutting down
 When the remaining battery charge is at level E
 When the battery malfunction is detected
 The Error LED lights during offline. However, it flashes when an error has occurred.
 For details about the battery charge levels and operation modes, see
"Operation Mode When
Battery is Low" on page 23
.
 You can select whether or not to stop command processing off-line with the customized
value. To set the customized value, see
"Software Settings" on page 47.
 The buzzer beeps five times when there is no more paper or an error has occurred. You can
disable the buzzer with the memory switches. For details on the memory switch settings, see
"Software Settings" on page 47.

Epson TM-P20 Specifications

General

Type	POS printer
Color	No
Print technology	Thermal
Maximum resolution	203 x 203 DPI
Rechargeable	Yes
Electromagnetic compatibility	FCC class A, CE
Mean cycles between failures (MCBF)	16000000
Power source type	AC, Battery
Battery life (max)	16 h
Product color	Black
Safety	EN
Country of origin	China
Sound pressure level (printing)	57 dB
Mean time between failures (MTBF)	120000 h
Media thickness	0.05 - 0.08 mm
Maximum roll diameter	40.4 mm
Supported paper width	58 mm
Wi-Fi standards	802.11a, 802.11b, 802.11g
USB connector	Mini-USB Type-B
Standard interfaces	NFC, USB 2.0
Connectivity technology	Wired & Wireless
Package depth	240 mm
Package width	195 mm
Package height	145 mm
Package weight	1482 g
Cables included	AC, USB
Quantity per pack	1 pc(s)
Operating relative humidity (H-H)	10 - 90 %
Pallet width	800 mm
Pallet height	1020 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	216 pc(s)
Quantity per pallet (UK)	288 pc(s)
Quantity per pallet layer	36 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	48 pc(s)

Weight and Dimensions

Depth	120 mm
Width	79 mm
Height	44 mm
