Appendix
Appendix
Product Specifications
Printing Specifications
dpi: dots per inch
1 The printing speed listed above are the values when using a new battery fully charged, the print density is 100%,
and at normal temperature (25°C). The printing speed changes automatically depending on the remaining battery,
the head temperature, and the number of print dots.
2 Programmable by commands.
3 Initial setting. Programmable by commands.
Printing method Thermal line printing
Dot density 203 × 203 dpi
Printing direction Unidirectional with friction feed
Maximum print speed *
1
100 mm/s {3.94"/s} (Standard mode)
40 mm/s {1.57"/s} (Fine mode) *
2
Printing width 48 mm {1.89"}, 384 dots
Characters per line Font A 32
Font B 42
Font C 42
Font D 38
Font E 48
Kanji Font A 16
Special Font A 32
Special Font B 42
Character spacing 0.25 mm {0.01"} (2 dots)
Paper feed speed 80 mm/s {3.15"/s} (when feeding with the Feed button)
Line spacing *
3
3.75 mm {0.15"}
