Epson TM-P20 Technical Reference Guide

93
Appendix
Wireless LAN Interface
Specification
 IEEE802.11a/b/g/n (2.4 GHz band or 5 GHz band) compliant wireless LAN communication compatible
 Infrastructure mode and 802.11 Ad-hoc mode are supported
 Support the IP address automatic acquisition function (DHCP, APIPA).
Communication standard
 IEEE802.11a (5 GHz)
 IEEE802.11b (2.4 GHz)
 IEEE802.11g (2.4 GHz)
 IEEE802.11n (2.4 GHz)
 IEEE802.11n (5 GHz)
Security
Security can be selected from among the following:
 WEP
 WPA
 WPA2-Personal
 WPA2-Enterprise
Initial settings
These settings apply when the printer is initialized in the Wireless module setup mode.
 You can connect to a WPA2-PSK (AES) access point using the settings above.
Countries where Wireless LAN can be used are limited. Since notes are provided for each country,
check the sheet supplied with the product.
Parameter Setting value
Communication standard 802.11b/g/n
Network mode Infrastructure mode
SSID EPSON_Printer
Encryption type WPA2-Personal
Passphrase EpsonNet
IP Address Automatically acquired by DHCP

Epson TM-P20 Specifications

General

Type	POS printer
Color	No
Print technology	Thermal
Maximum resolution	203 x 203 DPI
Rechargeable	Yes
Electromagnetic compatibility	FCC class A, CE
Mean cycles between failures (MCBF)	16000000
Power source type	AC, Battery
Battery life (max)	16 h
Product color	Black
Safety	EN
Country of origin	China
Sound pressure level (printing)	57 dB
Mean time between failures (MTBF)	120000 h
Media thickness	0.05 - 0.08 mm
Maximum roll diameter	40.4 mm
Supported paper width	58 mm
Wi-Fi standards	802.11a, 802.11b, 802.11g
USB connector	Mini-USB Type-B
Standard interfaces	NFC, USB 2.0
Connectivity technology	Wired & Wireless
Package depth	240 mm
Package width	195 mm
Package height	145 mm
Package weight	1482 g
Cables included	AC, USB
Quantity per pack	1 pc(s)
Operating relative humidity (H-H)	10 - 90 %
Pallet width	800 mm
Pallet height	1020 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	216 pc(s)
Quantity per pallet (UK)	288 pc(s)
Quantity per pallet layer	36 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	48 pc(s)

Weight and Dimensions

Depth	120 mm
Width	79 mm
Height	44 mm
