Epson TM-P20 Technical Reference Guide

68
3
After adjusting the parameters according to the menus, click the [Send] button to
send the changes to the printer.
4
On the Web page displayed after you send the changes, click the [Reset] button to
confirm that the changes have been applied.
When the IP address, SSID, and so on are changed, you need to change the settings on the host PC
and the access point so that they match the printer settings.
Certificate Import
Make the following settings in the Authentication - Certificate Import menu.
1
Set the file type of certificate.
2
Specify the certificate file to import.
3
If the file type of certificate is PKCS#12, enter the password.
4
Click [Import].
 [Roaming] and [AP Density] in the [Wireless] menu can be set only when the Wi-Fi model's
firmware is version 1.17 or later.
 [Wellknown Community Name] in the [SNMP] menu can be set only when the Wi-Fi model's
firmware is version 1.19 or later.
The initial value is enabled.
If you disable this setting, there are the following restrictions.
 TM drivers
The battery status cannot be acquired.
Port opening is extended by approximately 2 seconds.
 Deployment Tool
The model name cannot be acquired.
 EpsonNet Config/Monitoring Tool
The model name, status, and setting information cannot be acquired.
The setting cannot be changed.
 You can also select the following functions from the optional configuration menu.
 Administrator Information: Use to register administrator name and the printer location.
 Reset: Use to reset the interface card or restore the default settings.
 Password: Use to change the password.
Enable the time server when using a certificate.

Epson TM-P20 Specifications

General

Type	POS printer
Color	No
Print technology	Thermal
Maximum resolution	203 x 203 DPI
Rechargeable	Yes
Electromagnetic compatibility	FCC class A, CE
Mean cycles between failures (MCBF)	16000000
Power source type	AC, Battery
Battery life (max)	16 h
Product color	Black
Safety	EN
Country of origin	China
Sound pressure level (printing)	57 dB
Mean time between failures (MTBF)	120000 h
Media thickness	0.05 - 0.08 mm
Maximum roll diameter	40.4 mm
Supported paper width	58 mm
Wi-Fi standards	802.11a, 802.11b, 802.11g
USB connector	Mini-USB Type-B
Standard interfaces	NFC, USB 2.0
Connectivity technology	Wired & Wireless
Package depth	240 mm
Package width	195 mm
Package height	145 mm
Package weight	1482 g
Cables included	AC, USB
Quantity per pack	1 pc(s)
Operating relative humidity (H-H)	10 - 90 %
Pallet width	800 mm
Pallet height	1020 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	216 pc(s)
Quantity per pallet (UK)	288 pc(s)
Quantity per pallet layer	36 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	48 pc(s)

Weight and Dimensions

Depth	120 mm
Width	79 mm
Height	44 mm
