TM-T81
Specification
(STANDARD)
<Function 081> GS ( k pL pH cn fn m (cn = 48 , fn = 81)
[Name] PDF417: Print the symbol data in the symbol storage area
[Format] ASCII GS ( k p
L pH cn fn m
Hex 1D 28 6B p
L pH cn fn m
Decimal 29 40 107 p
L pH cn fn m
[Range] (p
L + pH × 256) = 3 (pL = 3 , pH = 0)
cn = 48
fn = 81
m = 48
[Description] • Encodes and prints the PDF417 symbol data in the symbol storage area using the
process of GS ( k <Function 080>.
[Notes] • Consider that a quiet zone (left, right, upward, and downward space areas, depending
on the PDF417 symbol specifications) must be ensured for PDF417 printing.
• In standard mode, a symbol higher than 831 dots cannot be printed with this printer.
<Function 082> GS ( k pL pH cn fn m (cn = 48 , fn = 82)
[Name] PDF417: Transmit the size information of the symbol data in the symbol storage area
[Format] ASCII GS ( k p
L pH cn fn m
Hex 1D 28 6B p
L pH cn fn m
Decimal 29 40 107 p
L pH cn fn m
[Range] (p
L + pH × 256) = 3 (pL = 3 , pH = 0)
cn = 48
fn = 82
m = 48
[Description] • Transmits the size information for the encoded PDF417 symbol data in the symbol
storage area using the process of GS ( k <Function 080>.
[Notes] • This function does not print.
• The size information does not include a quiet zone (left, right, upward, and downward
space areas, depending on the PDF417 symbol specifications).
