Epson TM-T81 Technical & Specifications Manual

Confidential
EPSON
TITLE
SHEET
REVISION
NO
SHEETNEXT
46 45
TM-T81
Specification
(STANDARD)
A
3.7 NV Graphics Print Mode
1) NV graphics print function
This function prints the NV graphics that are registered in the printer. The printer prints:
• Capacity of the NV graphics
• Occupied capacity of the NV graphics
• Unused capacity of the NV graphics
• Number of the NV graphics that are registered
• Key code, number of dots in X direction, number of dots in Y direction, number of color to be
defined
• NV graphics data
2) Mode start
c Open the paper roll cover and turn the power on while pressing the paper FEED button; then
press the paper FEED button once and close the paper roll cover.
d The instructions for printing the NV graphics are printed. Open the paper roll cover and
press the paper FEED button once and close the paper roll cover.
3) Mode end
Turn the power off.

Epson TM-T81 Specifications

General

Print Method	Thermal line printing
Autocutter	Yes
Interface	USB, Ethernet
Dimensions	140 mm (W) x 199 mm (D) x 146 mm (H)
Power Supply	AC 100 V - 240 V, 50 Hz - 60 Hz
Paper Width	79.5 ±0.5 mm
