Confidential
EPSON
TITLE
SHEET
REVISION
NO
SHEETNEXT
2 1
TM-T81
Specification
(STANDARD)
A
1. GENERAL SPECIFICATIONS
1.1 Printing Specifications
1) Printing method: Thermal line printing
2) Dot density: 180 dpi × 180 dpi
[dpi: dots per 25.4 mm {1"}]
3) Printing direction: Unidirectional with friction feed
4) Paper width: 80 mm {3.15"}
5) Printing width: 72 mm {2.83"}, 512 dot positions
6) Characters per line (default): Font A: 42
Font B: 56
7) Character spacing (default): Font A: 0.28 mm {0.01"} (2 dots)
Font B: 0.28 mm {0.01"} (2 dots)
NOTE: Programmable by control command.
8) Line spacing: 4.23 mm {1/6"}
NOTE: Programmable by control command.
9) Maximum printing speed:
Normal: 130 mm/s {5.1"/s}
Approximately 30.7 lps (4.23 mm {1/6"} feed)
Page mode printing: 130 mm/s {5.1"/s}
Bit-image printing: 130 mm/s {5.1"/s}
Raster bit-image printing:
130 mm/s {5.1"/s}
Ladder bar code, 2-dimensional code printing:
100 mm/s {3.9"/s}
NOTES: 1. The print speed listed above is the value when the printer prints with the standard print
density level at 24 V and 25°C {77°F}. The print speed may change automatically with
the condition of the supply voltage or the head temperature.
2. Printing speed may be slower depending on the data transmission speed and the
combination of control commands.
3. Low transmission speed may cause intermittent printing. It is recommended to transmit
data to the printer as fast as possible.
10) Paper feed speed: Approximately 130 mm/s {approximately 5.1"/s} (continuous paper feeding)
To Next Page
