Epson TM-T81 Technical & Specifications Manual

Confidential
EPSON
TITLE
SHEET
REVISION
NO
SHEETNEXT
99 100
A
TM-T81
Specification
(STANDARD)
GS :
[Name] Start/end macro definition
[Format] ASCII GS :
Hex 1D 3A
Decimal 29 58
[Description] • Starts or ends macro definition.
[Note] • The contents of the macro can be defined up to 2048 bytes.
GS B n
[Name] Turn white/black reverse print mode on/off
[Format] ASCII GS B n
Hex 1D 42 n
Decimal 29 66 n
[Range] 0 ≤ n ≤ 255
[Default] n = 0
[Description] • Turns white/black reverse print mode on or off.
• When the LSB of n is 0, white/black reverse mode is turned off.
• When the LSB of, n is 1, white/black reverse mode is turned on.
GS H n
[Name] Select print position of HRI characters
[Format] ASCII GS H n
Hex 1D 48 n
Decimal 29 72 n
[Range] 0 ≤ n ≤ 3 , 48 ≤ n ≤ 51
[Default] n = 0
[Description] • Selects the print position of HRI characters when printing a bar code.
n Print position
0, 48 Not printed.
1, 49 Above the bar code.
2, 50 Below the bar code.
3, 51 Both above and below the bar code.

Epson TM-T81 Specifications

General

Print Method	Thermal line printing
Autocutter	Yes
Interface	USB, Ethernet
Dimensions	140 mm (W) x 199 mm (D) x 146 mm (H)
Power Supply	AC 100 V - 240 V, 50 Hz - 60 Hz
Paper Width	79.5 ±0.5 mm
