Epson TM-T81 Technical & Specifications Manual

Confidential
EPSON
TITLE
SHEET
REVISION
NO
SHEETNEXT
65 66
A
TM-T81
Specification
(STANDARD)
ESC @
[Name] Initialize printer
[Format] ASCII ESC @
Hex 1B 40
Decimal 27 64
[Description] • Clears the data in the print buffer and resets the printer modes to the modes that were
in effect when the power was turned on.
Keeps the following data:
• Macro definition data.
• Contents stored in the NV user memory.
• Contents defined for the NV graphics (NV bit image).
• Maintenance counter value.
• Setting value specified with GS ( E.
ESC D n1...nk NUL
[Name] Set horizontal tab positions
[Format] ASCII ESC D n1...nk NUL
Hex 1B 44 n1...nk 00
Decimal 27 68 n1...nk 0
[Range] 1 ≤ n1 ≤ n2 ≤ ... ≤ nk ≤ 255
0 ≤ k ≤ 32
[Default] n = 8, 16, 24, 32, 40, ... , 232, 240, 248
[for Font A (12 × 24) in a standard character size width]
[Description] • Sets horizontal tab positions.
• n specifies the number of digits from the setting position to the left edge of the print
area.
• k is used to indicate the number of bytes set for the horizontal tab position.
ESC E n
[Name] Turn emphasized mode on/off
[Format] ASCII ESC E n
Hex 1B 45 n
Decimal 27 69 n
[Range] 0 ≤ n ≤ 255
[Default] n = 0
[Description] • Turns emphasized mode on or off.
• When the LSB of n is 0, emphasized mode is turned off.
• When the LSB of n is 1, emphasized mode is turned on.

Epson TM-T81 Specifications

General

Print Method	Thermal line printing
Autocutter	Yes
Interface	USB, Ethernet
Dimensions	140 mm (W) x 199 mm (D) x 146 mm (H)
Power Supply	AC 100 V - 240 V, 50 Hz - 60 Hz
Paper Width	79.5 ±0.5 mm
