Epson TM-T81

Confidential
EPSON
TITLE
SHEET
REVISION
NO
SHEETNEXT
69 70
A
TM-T81
Specification
(STANDARD)
ESC W xL xH yL yH dxL dxH dyL dyH
[Name] Set print area in page mode
[Format] ASCII ESC W x
L xH yL yH dxL dxH dyL dyH
Hex 1B 57 x
L xH yL yH dxL dxH dyL dyH
Decimal 27 87 x
L xH yL yH dxL dxH dyL dyH
[Range] 0 ≤ (x
L + xH × 256) ≤ 65535 (0 ≤ xL ≤ 255 , 0 ≤ xH ≤ 255)
0 ≤ (y
L + yH × 256) ≤ 65535 (0 ≤ yL ≤ 255 , 0 ≤ yH ≤ 255)
1 ≤ (dx
L + dxH × 256) ≤ 65535 (0 ≤ dxL ≤ 255 , 0 ≤ dxH ≤ 255)
1 ≤ (dy
L + dyH × 256) ≤ 65535 (0 ≤ dyL ≤ 255 , 0 ≤ dyH ≤ 255)
[Default] (x
L + xH × 256) = 0 (xL = 0 , xH = 0)
(y
L + yH × 256) = 0 (yL = 0 , yH = 0)
(dx
L + dxH × 256) = 512 (dxL = 0 , dxH = 2)
(dy
L + dyH × 256) = 1662 (dyL = 126 , dyH = 6)
[Description] • In page mode, sets the size and the logical origin of the print area.
• xL, xH specify the horizontal logical origin as [(xL + xH × 256) × (horizontal motion
unit)] from absolute origin.
• yL, yH specify the vertical logical origin as [(yL + yH × 256) × (vertical motion unit)]
from absolute origin.
• dxL, dxH specify the horizontal dimension of print area as [(dxL + dxH × 256) ×
(horizontal motion unit)].
• dyL, dyH specify the vertical dimension of print area as [(dyL + dyH × 256) × (vertical
motion unit)].
[Note] • The vertical dimension of the print area can be set to 234.53 mm {3324/360"}
maximum.
ESC \ nL nH
[Name] Set relative print position
[Format] ASCII ESC \ n
L nH
Hex 1B 5C n
L nH
Decimal 27 92 n
L nH
[Range] -32768 ≤ (nL + nH × 256) ≤ 32767
[Description] • Moves the print position to [(n
L + nH × 256) × (horizontal or vertical motion unit)] from
the current position.
• A positive number specifies movement to the right, and a negative number specifies
movement to the left.
