TM-T81
Specification
(STANDARD)
A
3.3.3 DIP Switches
3.3.3.1 Serial interface specification
1) DIP switch 1: 8 switches
Table 3.3.1 DIP Switch 1
SW 1 Function ON OFF
Factory
setting
1 Data reception error Ignored Prints '?' OFF
2 Receive buffer capacity 45 bytes 4K bytes OFF
3 Handshaking XON/XOFF DTR/DSR OFF
4 Word length 7 bits 8 bits OFF
5 Parity check Yes No OFF
6 Parity selection Even Odd OFF
7 Transmission speed selection See Table 3.3.2. ON
8 OFF
Table 3.3.2 Transmission Speed
Transmission Speed (bps) SW 1-7 SW 1-8
38400 (See *1) ON ON
4800 OFF ON
9600 ON OFF
19200 OFF OFF
bps: bits per second
NOTES: 1. The default value of the transmission speed is 9600 bps.
2. *1: The transmission speed can be selected by setting the transmission condition of the
serial interface.
3. The setting of the communication condition of the serial interface is performed with GS
( E.
As for each setting value, see GS ( E for details.
4. The communication condition of the serial interface set by GS ( E is enabled only when
DIP switches 1-7 and 1-8 are on. For other settings, the setting values by DIP switch 1
are enabled.
