TM-T81
Specification
(STANDARD)
GS W nL nH
[Name] Set print area width
[Format] ASCII GS W n
L nH
Hex 1D 57 n
L nH
Decimal 29 87 n
L nH
[Range] 0 ≤ (n
L + nH × 256) ≤ 65535 (0 ≤ nL ≤ 255 , 0 ≤ nH ≤ 255)
[Default] (n
L + nH × 256) = 512 (nL = 0 , nH = 2)
[Description] • In standard mode, sets the print area width to [(n
L + nH × 256) × (horizontal motion
unit)].
GS \ nL nH
[Name] Set relative vertical print position in page mode
[Format] ASCII GS \ n
L nH
Hex 1D 5C n
L nH
Decimal 29 92 n
L nH
[Range] -32768 ≤ (n
L + nH × 256) ≤ 32767
[Description] • In page mode, moves the vertical print position to [(n
L + nH × 256) × (vertical or
horizontal motion unit)] from the current position.
• A positive number specifies downward movement, and a negative number specifies
upward movement.
GS ^ r t m
[Name] Execute macro
[Format] ASCII GS ^ r t m
Hex 1D 5E r t m
Decimal 29 94 r t m
[Range] 1 ≤ r ≤ 255
0 ≤ t ≤ 255
m = 0, 1
[Description] • Executes the macro that was defined with GS :.
m Operation
0
Executes the macro r times continuously at an interval of [t × 100 ms].
1
After waiting for [t × 100 ms], flashes the LED indicator and waits for the
FEED button to be pressed. (The printer does nothing until then.) After
the button is pressed, executes the macro once.
Then repeats the operation r times.
