TM-T81
Specification
(STANDARD)
<Function 181> GS ( k pL pH cn fn m (cn = 49 , fn = 81)
[Name] QR Code: Print the symbol data in the symbol storage area
[Format] ASCII GS ( k p
L pH cn fn m
Hex 1D 28 6B p
L pH cn fn m
Decimal 29 40 107 p
L pH cn fn m
[Range] (p
L + pH × 256) = 3 (pL = 3 , pH = 0)
cn = 49
fn = 81
m = 48
[Description] • Encodes and prints the QR Code symbol data in the symbol storage area using the
process of GS ( k <Function 180>.
[Note] • Consider that a quiet zone (left, right, upward, and downward space areas, depending
on the QR Code symbol specifications) must be ensured for QR Code printing.
<Function 182> GS ( k pL pH cn fn m (cn = 49 , fn = 82)
[Name] QR Code: Transmit the size information of the symbol data in the symbol storage area
[Format] ASCII GS ( k p
L pH cn fn m
Hex 1D 28 6B p
L pH cn fn m
Decimal 29 40 107 p
L pH cn fn m
[Range] (p
L + pH × 256) = 3 (pL = 3 , pH = 0)
cn = 49
fn = 82
m = 48
[Description] • Transmits the size information for the encoded QR Code symbol data in the symbol
storage area using the process of GS ( k <Function 180>.
[Notes] • This function does not print.
• The size information does not include a quiet zone (left, right, upward, and downward
space areas, depending on the QR Code symbol specifications).
