TM-T81
Specification
(STANDARD)
[Description] • Defines the NV graphics data (raster format) as a record specified by the key codes
(kc1, kc2) in the NV graphics area.
• b specifies the number of the color of the defined data.
• xL, xH specify the number of dots in the horizontal direction as (xL + xH × 256).
• yL, yH specify the number of dots in the vertical direction as (yL + yH × 256).
• c specifies the color of the defined data.
c Defined data color
(*)
49 Color 1
• d specifies the defined data (raster format).
[Notes] • In cases where there is insufficient capacity available for storing NV graphics data
specified by (x
L + xH × 256) and (yL + yH × 256), this function is ignored.
• The number of items of NV graphics registered must be within 50 to shorten the
execution time of this function. The execution time is 60 seconds or less when the
number of items registered is within 50. The execution time for 100 items is 120
seconds or less.
• The [data value (k) + control information data value (24 bytes)] area of the NV
graphics data domain is used when this function is executed.
• NV graphics and NV bit image (FS q) cannot be defined simultaneously. When this
function is executed, all NV bit images are deleted.
<Function 69> GS ( L pL pH m fn kc1 kc2 x y (fn = 69)
[Name] Print the specified NV graphics data
[Format] ASCII GS ( L p
L pH m fn kc1 kc2 x y
Hex 1D 28 4C p
L pH m fn kc1 kc2 x y
Decimal 29 40 76 p
L pH m fn kc1 kc2 x y
[Range] (p
L + pH × 256) = 6 (pL = 6 , pH = 0)
m = 48
fn = 69
32 ≤ kc1 ≤ 126
32 ≤ kc2 ≤ 126
x = 1, 2
y = 1, 2
[Description] • Prints the NV graphics data defined by the key codes (kc1 and kc2).
• The graphics data is enlarged by x and y in the horizontal and vertical directions.
x, y
Vertical direction Horizontal direction
1 180 dpi 180 dpi
2 90 dpi 90 dpi
