Epson TM T88V Technical Reference Guide

106
Functions of each connector pin
Pin no. Signal name Signal direction Function
1 FG — Frame ground
2 TXD Output Transmission data
3 RXD Input Reception data
4 RTS Output Equivalent to DTR signal (pin 20)
6 DSR Input This signal indicates whether the host computer can
receive data.
SPACE indicates that the host computer can receive
data. MARK indicates that the host computer
cannot receive data.
When DTR/DSR control is selected, the printer
transmits data after confirming this signal (except if
transmitted using some ESC/POS commands).
When XON/XOFF control is selected, the printer does
not check this signal.
Changing DIP switch 2-7 lets this signal be used as a
printer reset signal.
When you use this signal as the printer’s reset signal,
the printer is reset when the signal remains MARK for
a pulse width of 1 ms or more.
7 SG — Signal ground
20 DTR Output 1) When DTR/DSR control is selected, this signal
indicates whether the printer is BUSY.
• SPACE status
Indicates that the printer is ready to receive data.
• MARK status
Indicates that the printer is BUSY. Set BUSY conditions
with DIP switch 2-1.
2) When XON/XOFF control is selected, the signal
indicates that the printer is properly connected and
ready to receive data from the host. The signal is
always SPACE, except in the following cases:
• During the period from when power is turned on to
when the printer is ready to receive data.
• During the self-test.
25 INT Input Changing DIP switch 2-8 enables this signal to be
used as a reset signal for the printer. The printer is
reset if the signal remains at SPACE for a pulse width
of 1 ms or more.

Epson TM T88V Specifications

General

Dimensions (WxDxH)	145 x 195 x 148 mm
USB port	Yes
Standard interfaces	RS-232, USB 2.0
Serial interface type	RS-232
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Type	POS printer
Print speed	11.8 ips
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Safety	UL1950/CSA C22.2 No. 950
Certification	FCC/ICES-003
Built-in barcodes	2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF-14, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Country of origin	China
Autocutter durability	2 million cuts
Mean time between failures (MTBF)	360000 h
Product color	Black
Maximum roll diameter	83 mm
Supported paper width	80, 58 mm
Printing media thickness	55 - 80 µm
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN	No
Input current	1.8 A
Power supply type	DC
Pallet width	800 mm
Pallet height	2550 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2660 g
Quantity per pack	1 pc(s)
