72
Arranging the Cables
Route the cables when using the connector cover.
Pass the cables through cable exits in the connector cover. The connector cover has cable exits on
the back and both sides.
You can also route the cables out the front by passing them through the notch in the printer
bottom.
If you want to pass the USB cable thro
ugh the cable exit on the back, fit the cable under the hook
on the printer to prevent the cable from coming off.
After the cable arrangement, turn over the printer, and make sure the cables are not pinched.
Hooks
