Epson TM T88V Technical Reference Guide

98
USB Low Power Consumption Mode
With the TM-T88V, you can enable the USB low power consumption mode with DIP Switch 1-8,
just as you can with the TM-T88IV. (See "For Ethernet/Wireless LAN/USB Interface" on page
44.)
Maintenance Counter
The TM-T88V has a maintenance counter just as the TM-T88IV has.
Buzzer
TM-T88V is available with a built-in buzzer or without the buzzer. Even if you purchase the one
without the buzzer, you can attach an optional external buzzer. You can beep the buzzer with the
pulse signal using a command. (See "Setting the Internal Buzzer (for Model with an Int
ernal
Buzzer)" on page 65, "Connecting the Optional External Buzzer" on page 66.)
Power Supply Box
The optional power supply box (OT-BX88V) is available to be attached under the TM-T88V to
hold the power unit, just as the OT-BX88 has been available for the TM-T88IV.
For detailed information about ESC/POS commands, see the ESC/POS Application
Programming Guide.

Epson TM T88V Specifications

General

Dimensions (WxDxH)	145 x 195 x 148 mm
USB port	Yes
Standard interfaces	RS-232, USB 2.0
Serial interface type	RS-232
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Type	POS printer
Print speed	11.8 ips
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Safety	UL1950/CSA C22.2 No. 950
Certification	FCC/ICES-003
Built-in barcodes	2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF-14, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Country of origin	China
Autocutter durability	2 million cuts
Mean time between failures (MTBF)	360000 h
Product color	Black
Maximum roll diameter	83 mm
Supported paper width	80, 58 mm
Printing media thickness	55 - 80 µm
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN	No
Input current	1.8 A
Power supply type	DC
Pallet width	800 mm
Pallet height	2550 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2660 g
Quantity per pack	1 pc(s)
